Home / Product / HIPS Plastic Sheet Roll / HIPS Plastic Roll For Blister Electronic Packaging
HIPS Plastic Roll For Blister Electronic Packaging
Pulixin is an excellent and leading plastic sheet Manufacturer & factory in China. We have advanced technology and equipment, mature foreign trade and export experience, and have established good cooperative relations with customers in more than 60 countries. Free samples supply, OEM & ODM accepted
- Brand: PULIXIN
- Origin: Shanghai, China
- MOQ: 5 tons
- Thickness: 0.3~2mm
- Width: 300~850mm
- Application: Thermoforming
- Send Inquiry
-
- Email: lindy@pulixin.com
- Phone: +8615221762039
- WhatApp
- Wechat
Description
Because the HIPS molecule contains 5-15% of rubber, which affects its fluidity to a certain extent, the injection pressure and molding temperature should be higher. Its cooling rate is slower than that of PS, so sufficient holding pressure, holding time and cooling time are required. The molding cycle will be slightly longer than that of PS, and its processing temperature is generally 190-240℃. HIPS resin absorbs water slowly, so it does not need to be dried under normal circumstances. Sometimes too much moisture on the surface of the material will be absorbed, thereby affecting the appearance quality of the final product. Drying at 160°F for 2-3 hours will remove excess water. There is a special white edge problem in HIPS parts, which can be improved by increasing the mold temperature and clamping force, reducing the holding pressure and time, etc. The water trapping in the product will be more obvious.
HIPS is a modified material of PS, which contains 5-15% rubber in its molecule. Its toughness is about four times higher than that of PS, and its impact strength is greatly improved. It has flame-retardant, stress-cracking resistance, high gloss, and extremely High impact strength grade, glass fiber reinforced grade and low residual volatilization grade. Other important properties of standard HIPS: bending strength 13.8-55.1MPa; tensile strength 13.8-41.4MPa; elongation at break 15-75%; density 1.035-1.04 g/ml; it has PS with molding processing and strong tinting strength The advantages. HIPS products are opaque. HIPS has low water absorption, no need for pre-drying during processing.
1.Conductive sheet: Our company produces conductive sheet that is widely used in electronic tray blister, and the surface resistance can reach the 4-6 power of 10. The advantages are not disturbed by weather factors. Manufacturers used: Shanghai Jiusheng Blister, Leiyu Blister, Xumei Blister, etc.
2. Semi-conductive sheet: Our company produces conductive sheet, which is widely used in electronic tray blister, and the surface resistance can reach 10 to the 6-9th power. Manufacturers used: Shanghai Jiusheng Blister, Leiyu Blister, Xumei Blister, etc.
3. Ordinary anti-static sheet: Our company produces conductive sheet, which is widely used in electronic tray blister, and the surface resistance can reach 10 to the 9-12 power. Advantages: affordable, disadvantages: affected by the weather, if not affected by the weather, you can choose conductive sheets or permanent antistatic sheets. Manufacturers used: Shanghai Jiusheng Blister, Leiyu Blister, Xumei Blister, etc.
Product name: HIPS Plastic Roll For Blister Electronic Packaging
Thickness: 0.2~2mm
Width:300~1050mm
Density:1.03~1.05g/cm3
Colors:Natural color,White color,Milky white color,Brown color,Black color,Red Color,Blue Color ,Yellow Color,Coffee Color
Transparency:semi-transparency,opaque
Application:Thermoforming food packaging,cup lids,Electronic tray,cosmetic packaging
Surface:Glossy/matt
Form:by roll or cut sheet form
Outer diameter:200-700mm
Inner core diameter:3″(76mm)
Certificate:SGS,TDS,MSDS
Type:HIGH IMPACT PS NORMAL SHEET ROLL
HIGH IMPACT PS ANTI-STATIC SHEET ROLL
HIGH IMPACT PS ESD SHEET ROLL
HIGH IMPACT PS CONDUCTIVE SHEET ROLL
Thickness: 0.2~2mm
Width:300~1050mm
Density:1.03~1.05g/cm3
Colors:Natural color,White color,Milky white color,Brown color,Black color,Red Color,Blue Color ,Yellow Color,Coffee Color
Transparency:semi-transparency,opaque
Application:Thermoforming food packaging,cup lids,Electronic tray,cosmetic packaging
Surface:Glossy/matt
Form:by roll or cut sheet form
Outer diameter:200-700mm
Inner core diameter:3″(76mm)
Certificate:SGS,TDS,MSDS
Type:HIGH IMPACT PS NORMAL SHEET ROLL
HIGH IMPACT PS ANTI-STATIC SHEET ROLL
HIGH IMPACT PS ESD SHEET ROLL
HIGH IMPACT PS CONDUCTIVE SHEET ROLL
Product parameters
| HIPS Sheet Roll Test Item | Test method | Unit | Properties |
| Specific gravity | ASTM D792 | g/cm3 | 1.05 |
| Impact Strength | ASTM D256 | mpa | 35 |
| Tensile Strength | ASTM D638 | mpa | 29 |
| Heat Deflection Temperature | ASTM D648 | ℃ | 85 |
| Flexural Strength | ASTM D790 | mpa | 36 |
| COLOR | Visual Inspection | / | White (Colorable) |
| SURFACE RESISTANCE | ASTM D257 | Ω | 10^9~10^11 |
